DESIGN.md · Analysis

Audi F1 Australian Grand Prix 2026

f1.audi.com.au · 14 Jul 2026 · 47 colors · audiType, Verdana, sans-serif

Audi F1 Australian Grand Prix 2026

A high-performance motorsport brand experience centered on Audi's Formula 1 debut at the 2026 Australian Grand Prix. The design system balances precision engineering aesthetics with dynamic energy, using a bold red accent against deep charcoal surfaces to convey speed, luxury, and technical mastery.

Colors

surface#131313
surface-dim#0a0a0a
surface-bright#1f1f1f
surface-container-lowest#0f0f0f
surface-container-low#151515
surface-container#1b1b1b
surface-container-high#262626
surface-container-highest#303030
on-surface#ffffff
on-surface-variant#c2c2c2
inverse-surface#ffffff
inverse-on-surface#131313
outline#707582
outline-variant#505050
surface-tint#eb0d3f
primary#eb0d3f
on-primary#000000
primary-container#ff4d6d
on-primary-container#000000
inverse-primary#ff6b7f
secondary#3e3e3e
on-secondary#ffffff
secondary-container#505050
on-secondary-container#ffffff
tertiary#ecedee
on-tertiary#000000
tertiary-container#d0d0d0
on-tertiary-container#131313
error#ff4d6d
on-error#000000
error-container#ff6b7f
on-error-container#000000
primary-fixed#ff4d6d
primary-fixed-dim#eb0d3f
on-primary-fixed#000000
on-primary-fixed-variant#1a1a1a
secondary-fixed#505050
secondary-fixed-dim#3e3e3e
on-secondary-fixed#ffffff
on-secondary-fixed-variant#c2c2c2
tertiary-fixed#ecedee
tertiary-fixed-dim#d0d0d0
on-tertiary-fixed#000000
on-tertiary-fixed-variant#505050
background#131313
on-background#ffffff
surface-variant#3e3e3e

Typography

display
fontFamily: audiType, Verdana, sans-serif · fontSize: 80px · fontWeight: 700 · lineHeight: 88px · letterSpacing: -0.02em
headline-lg
fontFamily: audiType, Verdana, sans-serif · fontSize: 48px · fontWeight: 700 · lineHeight: 56px · letterSpacing: -0.01em
headline-md
fontFamily: audiType, Verdana, sans-serif · fontSize: 32px · fontWeight: 700 · lineHeight: 40px · letterSpacing: 0em
title-lg
fontFamily: audiType, Verdana, sans-serif · fontSize: 20px · fontWeight: 700 · lineHeight: 28px · letterSpacing: 0.01em
body-lg
fontFamily: audiType, Verdana, sans-serif · fontSize: 18px · fontWeight: 400 · lineHeight: 28px · letterSpacing: 0em
body-md
fontFamily: audiType, Verdana, sans-serif · fontSize: 16px · fontWeight: 400 · lineHeight: 24px · letterSpacing: 0em
label-md
fontFamily: audiType, Verdana, sans-serif · fontSize: 14px · fontWeight: 700 · lineHeight: 20px · letterSpacing: 0.01em
label-sm
fontFamily: audiType, Verdana, sans-serif · fontSize: 10px · fontWeight: 700 · lineHeight: 14px · letterSpacing: 0.1em

Design guidance

Overview

Audi F1 Australian Grand Prix 2026 embodies a design philosophy rooted in **Precision Motorsport Minimalism**—a aesthetic that merges the austere, high-tech language of Formula 1 engineering with the luxury restraint of the Audi brand. The interface prioritizes clarity and speed, using a deep charcoal canvas (#131313) as the dominant surface, punctuated by a vivid racing red (#eb0d3f) that commands attention on every critical interaction. The visual experience evokes the cockpit of a high-performance vehicle: every element is purposeful, every color choice deliberate, every interaction responsive. The brand personality is authoritative yet approachable—technical precision without coldness, luxury without pretension. Voice: direct, energetic, confident. Example: "Albert Park was our first chapter. Register now to own the next."

Colors

The color system operates on a **dark-first, accent-driven** model. The primary surface is deep charcoal (#131313, rgb(19, 19, 19)), which serves as the page background and primary container for all content. This near-black creates maximum contrast for white text (#ffffff) at 100% opacity, ensuring WCAG AAA compliance (contrast ratio 21:1). The primary accent is Audi Racing Red (#eb0d3f, rgb(235, 13, 63)), applied exclusively to call-to-action buttons, focus states, and brand-critical interactive elements. On hover, primary buttons invert to black (#000000) with a red border at 40% opacity (#eb0d3f66), creating a tactile feedback loop. Secondary surfaces use a mid-charcoal (#1b1b1b) for elevated containers and cards, with a surface-container-highest tier at #303030 for modals and overlays.

Typography

The type system is built on **audiType**, a proprietary Audi typeface loaded via @font-face (woff2 format), with Verdana and sans-serif as fallbacks. The hierarchy spans eight levels: display (80px, 700 weight, -0.02em tracking) for hero headlines like "Albert Park was our first chapter"; headline-lg (48px, 700, -0.01em) for section titles; headline-md (32px, 700) for subsections; title-lg (20px, 700, 0.01em) for card headers; body-lg (18px, 400) for long-form content; body-md (16px, 400) for standard paragraph text; label-md (14px, 700, 0.01em) for button text and interactive labels; and label-sm (10px, 700, 0.1em tracking, uppercase) for micro-copy and metadata. All headlines use 150% font-stretch for a compressed, dynamic appearance. Body text maintains a 1.5 line-height ratio (24px for

Layout

The layout system uses a **60/40 split grid** at breakpoint 64rem (1024px), with the left column occupying 58.411% and the right 41.599% of the viewport. Below 64rem, the layout stacks vertically with full-width cards. The container max-width is 1920px, maintaining a 12-column grid structure. Horizontal padding is 12px on mobile, scaling to 24px (gutter) on tablet and desktop. Vertical rhythm follows an 8px unit system: spacing-xs (4px) for micro-adjustments, spacing-sm (12px) for tight grouping, spacing-md (24px) for standard section separation, spacing-lg (40px) for major section breaks, and spacing-xl (64px) for full-page rhythm. Cards use 24px internal padding (spacing-md) with 12px gaps between stacked elements. The dashboard hero section uses a 60/40 split where the left side contain

Elevation & Depth

Depth is conveyed through a **three-tier shadow and backdrop system**. Level 1 (Base): no shadow; surface-container (#1b1b1b) with 1px border at rgba(255, 255, 255, 0.2). Level 2 (Standard Card): box-shadow: 0 3px 8px rgba(0, 0, 0, 0.15), backdrop-filter: blur(12px), background: rgba(255, 255, 255, 0.05). Level 3 (Elevated/Modal): box-shadow: 0 8px 32px rgba(0, 0, 0, 0.25), backdrop-filter: blur(40px), background: rgba(255, 255, 255, 0.1). Interactive elements (buttons, circle-icons) use a 0.3s transition on hover to shift between levels. The video background layer sits at z-index 10 (fixed, b

Shapes

The shape language follows **Precision Geometric Modernism**: sharp, intentional radii that reflect engineering precision rather than organic softness. Buttons and interactive elements use border-radius: 999px (full pill shape) for maximum visual impact and touch-target clarity (44px minimum height). Standard cards use border-radius: 1rem (16px) for a balanced, professional appearance. Input fields use border-radius: 0.5rem (8px) for a more structured, form-like aesthetic. Circle icons (41px × 41px) use border-radius: 50% to create perfect circles for icon containers. The rationale: pill-shape

Components

Action Elements Buttons are the primary interaction mechanism. The primary button uses background: {colors.primary} (#eb0d3f), text-color: {colors.on-primary} (black), padding: 6px 24px, height: 44px, border-radius: 999px, and font-size: 14px (label-md weight 700). On hover, the background inverts to black with a 1px border at #eb0d3f66 (40% opacity red), and text color shifts to red. The transition timing is 0.3s cubic-bezier(0.4, 0, 0.2, 1). Secondary buttons mirror this structure but start with background: black and text: white, inverting on hover. Glass buttons use backdrop-filter: blur(40px), background: rgba(255, 255, 255, 0.1), and no border, creating a frosted-glass effect over video backgrounds. All buttons include a circle-icon (41px × 41px) with an arrow SVG, rotated -45deg

Do's and Don'ts

**Do**

  • Do use the primary red (#eb0d3f) exclusively on CTAs, focus states, and brand-critical interactive elements—never on passive text or backgrounds.
  • Do maintain minimum 44px touch targets for all interactive elements (buttons, circle-icons, list items) to ensure mobile accessibility.
  • Do apply backdrop-filter: blur(40px) with rgba(255, 255, 255, 0.1) background on glass overlays to create depth without obscuring video backgrounds.
  • Do use the 60/40 grid split at breakpoint 64rem to create a dynamic, asymmetrical layout that guides the eye to the primary content.
  • Do pair audiType display (80px, 700 weight) with -0.02em letter-spacing on hero headlines to create a compressed, energetic appearance.
  • Do transition all interactive states (hover, focus, active) over 0.3s using cubic-bezier(0.4, 0, 0.2, 1) for consistent motion feedback.

**Don't**

  • Don't use the primary red on body text, backgrounds, or non-interactive elements—it must remain reserved for CTAs and focus states to maintain visual hierarchy.
  • Don't apply shadows or elevation to elements below 44px in height; use border or background-color shifts instead to maintain clarity at small scales.
  • Don't use system fonts (system-ui, -apple-system) in place of audiType; always load the custom typeface via @font-face to preserve brand identity.
  • Don't exceed 40px padding on cards or containers; use 24px as the standard to maintain visual density and prevent excessive whitespace.
  • Don't apply text-shadow on body text over dark backgrounds; reserve it only for label-sm overlaid on photographic content.
  • Don't animate opacity transitions on the primary button; use background-color and border-color shifts instead for snappier, more responsive feedback.
